THE ROYAL VAUXHALL TAVERN TECHNICAL SPEC 2019


SOUND SYSTEM (DJ BOX)

DJ Mixer

Formula Sound FSM-600 Fixed Format Stereo DJ Mixer
10 stereo line inputs
2 microphone inputs
1 mic ch used for DJ mic
5 ch shared between DJ devices:
2 x CDJ 2000 Nexus CD players
1 x DVD player
2 x Denon DN-HC4500 rack mount DJ controller (Available on request)
2 x PC DJ/Tablet/Smartphone inputs – one via phono sockets, one via a 2.5mm minj jack plug
(Note: the two PC DJ/Tablet/Smartphone inputs have a boosted gain input level)
1 x stereo aux output (routed to stage monitor send)
Assignable crossfader.

PA Mixer

Professional 16 ch + 2 stereo ch Soundcraft LX7 II 16 mixing desk
9 ch used for stage mics
6 ch used for stage line inputs (1/4” jack) for musical instruments etc
1 ch used for effects return
1 x Alesis Microverb4 digital effects unit
(The 9 xlr mic channels and 6 line channels are hard wired from the stage)
Behringer 8ch DI box with cut and boost
6 Aux out channels:
Aux 1 sends to stage monitor amp
Aux 6 sends to effects unit
Aux 3,4 and 5 send to aux send sockets on stage
1 x Main stereo output
4 x group outputs

Stage

2 x 12 channel fixed stage box – stage left and right (mix of mic and line channels on each)
Behringer 8ch DI box with db cut and boost available
10 power sockets
4 x Stage monitor speaker sockets on stage

Mics

2 x Sennheiser wireless microphones
2 x Shure SM58 wireless microphones
3 x Shure WH30 wireless head microphones
3 x Tetrad AKG Digital headmics
2 x Shure SM58 cable microphones
2 x Shure PG48 cable mics
2 x ‘other’ cable microphones
1 x wired DJ microphone
Microphone stands and music stands available

AMPLIFICATION SYSTEM AND SPEAKERS

1 x 700w DJ monitor amp feeding 2 x JBL mid and hi range speaker cabinets
1 x 700w DJ monitor and feeding 1 x JBL sub bass speaker cabinet
1 x 800w x 2 ch Stage monitor amp feeding 2 x JBL full range stage monitors
Feed from mixing desk to digital eq and crossover to drive the following:
2 x 1000w 2 ch amps feeding 4 x JBL mid and hi range speaker cabinets
2 x 2500w 2 ch amps feeding 2 x JBL sub bass speaker cabinets
System capacity fully protected by intelligent digital protection system

LIGHTING SYSTEMS

Stage lighting

7 x 500w Fresnel lanterns
1 x 1000w Profile lantern
2 x Minuette Profile 500w lanterns
2 x 1000w Par cans
2 x LED colour rear stage lights dmx controlled
2 x LED Strip dmx controlled
1 x UV strip
1 x Strand 100 Plus 16ch x 2 preset console

Other stage equipment

2 x Remote controlled electric projector screens
1 x Digital projector driven by PC input (VGA) or DVD player

Club lighting

6 x Moving heads – QTX MHS-30 (DMX controlled)
3 x Scanners – QTX Synoscan DMX controlled)
1 x Laser (DMX controlled)
8 x UV Bulbs
3 x UV Strips
1 x DMX Computer

Effects

1 x Haze machine (DMX controlled)
2 x snow machines with remote control

All lights/effects controlled from DJ box

General equipment

Fully air-conditioned and heated
2 high capacity Vent-Axia extraction fans.
Fully stocked bar with large chilled cellar
Touch screen computerised POS system
High capacity icemaker
Freezer and additional storage fridges
Coat check printer for full capacity coat-check
Wristband or ticket entry printer
Internal and External CCTV system
Capacity with Tables and stools for seating 160
Capacity without stools and tables 380
Fewer tables and stools = increased capacity
